VGA Cable



单价 面议对比
询价 暂无
浏览 173
发货 广东东莞市付款后3天内
过期 长期有效
更新 2018-06-08 17:23

联系方式
加关注0

东莞中钜资讯光电有限公司

VIP   VIP会员第1年
资料未认证
保证金未缴纳
详细说明

产品特性:

还是电压30V

还是温度80

特性打扰75Ω±5


功能说明:

视频领域投影显示器

http://www.greatchinacom.com/cn_asp/productshow.asp?id=812

规格参数
●Structure:
 Tinned Stranded Copper Conductor.
 Coaxial Insulation:Foam-PE
 Hook-up Wire Insulation:Semi-rigid Polyvinyl (SR-PVC)
 Tinned Copper Wire Spiral or Braid Shield (Coaxial)
 Filler Cotton.
 Drain Wire Laid between Aluminum mylar and Braid
 Braid:Tinned Copper Wire Outer Shield
 Coverage Rate:Minimum 85%
 Polyvinyl Chloride(PVC) Jacket



Spec NO: Conductor No.of core Insulation Diameter Insulation Jacket Diameter
AWG No./MM MM MM
5DG2 28 7/0.127 3C 2.5 FPE 7.5
28 7/0.127 4C 0.82 SR-PVC
5DG2 28 7/0.127 3C 2.5 FPE 8.0
28 7/0.127 5C 0.82 SR-PVC
5DG2 28 7/0.127 3C 2.5 FPE 8.1
28 7/0.127 6C 0.82 SR-PVC
5DG2 28 7/0.127 3C 2.5 FPE 8.2
28 7/0.127 7C 0.82 SR-PVC
5DG2 28 7/0.127 3C 2.5 FPE 8.5
28 7/0.127 8C 0.82 SR-PVC
5DG1 28 7/0.127 3C 2.5 FPE 8.0
26 7/0.16 4C 1.0 SR-PVC
5DG1 28 7/0.127 3C 2.5 FPE 8.1
26 7/0.16 5C 1.0 SR-PVC
5DG1 28 7/0.127 3C 2.5 FPE 8.2
26 7/0.16 6C 1.0 SR-PVC
5DG1 28 7/0.127 3C 2.5 FPE 8.4
26 7/0.16 7C 1.0 SR-PVC
5DG1 28 7/0.127 3C 2.5 FPE 8.5
26 7/0.16 8C 1.0 SR-PVC
5DG0 28 7/0.127 3C 2.5 FPE 8.0
24 7/0.2 4C 1.07 SR-PVC
5DG0 28 7/0.127 3C 2.5 FPE 8.1
24 7/0.2 5C 1.07 SR-PVC
5DG0 28 7/0.127 3C 2.5 FPE 8.2
24 7/0.2 6C 1.07 SR-PVC
5DG0 28 7/0.127 3C 2.5 FPE 8.5
24 7/0.2 7C 1.07 SR-PVC
5DG0 28 7/0.127 3C 2.5 FPE 8.5
24 7/0.2 8C 1.07 SR-PVC

Physical Characters:
 Temperature rating:80℃
 Voltage rating:300V
 Flame test of cable:VW-1

Transmission Characters:
 1.Attenuation:
Frequency ( MHz) 1 4 5 7 9 10.0 30.0 50.0 100.0
Attenuation (MAX) dB/100FT 0.6 1.2 1.4 1.7 2.0 2.1 3.8 5.1 7.6

 2.Impedance:75±4Ω
 3.Velocity of Propagation:78% (Nominal)
